HIK-IC2449 OUT
Wizview 4MP Outdoor
- 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
- Outputs max. 4 MP (2G88 x 1520) @20 fps, and supports 2560×1440 (2560 x 1440) @25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in warm light, and the max. illumination distance is 50 m.
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Abnormality detection: Motion detection, video tampering, audio detection, noSD card, SD card full, SD card error, network disconnection,
- IP conflict, illegal access, and voltage detection.
- Supports max. 256 G Micro SD card; built in Mic.
- 12 VDC/PoE power supply, easy for installation.
- IP67 protection.
- SMD Plus
Tag: Security Camera, Wizview
DATA SHEETPESAN SEKARANG
| Camera | |
|---|---|
| Image Sensor | 1/1.8" CMOS |
| Max. Resolution | 2688 (H) x 1520 (V) |
| ROM | 128 MB |
| RAM | 256 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0005 lux@F1.0 |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 50 m (Warm light) |
| Illuminator Control | Auto / Manual |
| Illuminator Number | 4 (Warm light) |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M16 |
| Focal Length | 3.6 mm; 6 mm |
| Max. Aperture | F1.0 |
| Field of View |
3.6 mm: H 94°; V 50°; D 113° 6 mm: H 58°; V 31°; D 67° |
| Iris Control | Fixed |
| Intelligence | |
| IVS | Intrusion, Tripwire (vehicle & human classification) |
| SMD | SMD Plus |
| Smart Search | Works with Smart NVR |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Sub Stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Frame Rate |
Main: 2688×1520 @1–20 fps / 2560×1440 @1–25/30 fps Sub: 704×576 @1–25 fps / 704×480 @1–30 fps |
| Stream Capability | 2 streams |
| Resolution | 4M, 3M, 1080p, 1.3M, 720p, D1, VGA, CIF |
| Bit Rate Control | VBR; CBR |
| Video Bit Rate | H.264: 32–6144 kbps; H.265: 12–6144 kbps |
| WDR | 120 dB |
| Noise Reduction | 3D NR |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Protocol | IPv4, IPv6, HTTP, TCP, UDP, RTSP, FTP, DHCP, DNS, NTP, ONVIF |
| User/Host | 20 (48 Mbps) |
| Storage | FTP; SFTP; Micro SD (max 256 GB); NAS |
