Port 6KV Lightning Protection

• All ports support 6KV lightning protection, PSE short-circuit protection, PoE overload, power supply over-temperature protection, over-voltage protection, surge current protection and other protection features.

Switching Performance

• Non blocking switching architecture, all ports support wire speed forwarding;
• Provide two 10/100M RJ45 uplink simultaneously;
• Support IEEE 802.3x full dual and half dual backpressure flow control.
• Support port automatic flipping (Auto MDI/MDIX).

PoE Features

• Complies with the IEEE802.3af&at standard, with a maximum PoE power of 30W per port;
• Support PoE short circuit protection, overcurrent protection, over temperature protection, etc;
• Port 4 supports IEEE802.3bt with a maximum power of 60W. Ease of Use
• Plug and play, no configuration required, simple and convenient to use;
• Zero configuration feature, power is automatically supplied to adaptive devices.

AI Intelligent Recognition

• Intelligent recognition of long-distance mode, adaptive deceleration from 130 meters (100M/S) to 250 meters (10M/S);
• AI PoE automatic recognition, automatic detection of powered ports, detection of dead devices, power off and restart the device.

Port 6KV Lightning Protection

• All ports support 6KV lightning protection, PSE short-circuit protection, PoE overload, power supply over-temperature protection, over-voltage protection, surge current protection and other protection features.

AI Smart Button

• AI VLAN: Isolate ports 1-4 from each other, which can effectively suppress network storms and improve network performance;
• AI Extend: 1-4 ports support 250 meters long-distance power supply (recommended to use super five or more network cables).
