HIK-8016M
16 Port AI Poe Switch
Switching Performance
- Non blocking switching architecture, all ports support wire speed forwarding.
- Provide two 10/100M RJ45 uplink simultaneously.
- Support IEEE 802.3x full dual and half dual backpressure flow control.
- Support port automatic flipping (Auto MDI/MDIX).
PoE Features
- Complies with the IEEE802.3af&at standard, with a maximum PoE power of 30W per port.
- Support PoE short circuit protection, overcurrent protection, over temperature protection, etc.
- Port 15-16 support IEEE802.3bt with a maximum power of 60W.
Ease of Use
- Plug and play, no configuration required, simple and convenient to use.
- Zero configuration feature, power is automatically supplied to adaptive devices.
AI Intelligent Recognition
- Intelligent recognition of long-distance mode, adaptive deceleration from 130 meters (100M/S) to 250 meters (10M/S);
- AI PoE automatic recognition, automatic detection of powered ports, detection of dead devices, power off and restart the device;
Port 6KV lightning protection
- All ports support 6KV lightning protection, PSE short-circuit protection, PoE overload, power supply over-temperature protection, over-voltage protection, surge current protection and other protection features.
Tag: Networking, Switch
DATA SHEETPESAN SEKARANG
| Specification | |
|---|---|
| Ports |
16 x 10/100 Mbps PoE RJ45 (port 1~16) 2 x 10/100/1000 Mbps RJ45 (port 17~18) 1 x 1000M SFP port |
| Standards |
IEEE 802.3ix, IEEE 802.3us, IEEE 802.3xx, IEEE 802.3aL, IEEE 802.3atx, IEEE 802.3bt |
| Performance |
Bandwidth: 7.2 Gbps Packets Forwarding Rate: 5.4 Mpps MAC Table Size: 8K Forwarding Type: Storage and Forwarding |
| LED Indicator |
Power Indicator LINK/ACT Indicator PoE Indicator |
| PoE | 1/2(+), 3/6(-) |
| Power |
Port 15-16 max power: 60 W PoE budget: 150 W |
| Dimension | W x D x H: 210 mm x 152 mm x 40 mm |
| Environment |
Working Temperature: 0°-40°C Storage Temperature: -40° to 70°C Working Humidity: 10%-90% RH non-condensing Storage Humidity: 5%-90% RH non-condensing |
| Safety Compliance | CE / ROHS / FCC / CCC |
